Electrical Specifications
|
Feature
|
Units
|
30/60
|
1/100
|
3/100
|
6/100
|
10/100
|
15/100
|
25/100
|
|
Minimum supply voltage
|
VDC
|
8
|
10
|
|
Nominal supply voltage
|
VDC
|
48
|
85
|
|
Maximum supply voltage
|
VDC
|
55
|
95
|
|
Maximum continuous power output
|
W
|
1370
|
80
|
235
|
470
|
800
|
1125
|
2000
|
|
Efficiency at rated power
(at nominal conditions)
|
%
|
> 99
|
|
Maximum output voltage
|
|
Up to 96% of DC bus voltage
|
|
Ic, Amplitude sinusoidal/DC
continuous current
|
A
|
30
|
1
|
3
|
6
|
10
|
15
|
25
|
|
Sinusoidal continuous RMS
current limit (Ic)
|
A
|
21
|
0.7
|
2.1
|
4.2
|
7.1
|
10
|
17.7
|
|
Peak current limit
|
A
|
2 x Ic
|
|
Feature
|
Units
|
3/200
|
6/200
|
10/200
|
|
Minimum supply voltage
|
VDC
|
20
|
|
Nominal supply voltage
|
VDC
|
170
|
|
Maximum supply voltage
|
VDC
|
195
|
|
Maximum continuous power output
|
W
|
485
|
975
|
1650
|
|
Efficiency at rated power
(at nominal conditions)
|
%
|
> 99
|
|
Maximum output voltage
|
|
Up to 96% of DC bus voltage
|
|
Ic, Amplitude sinusoidal/DC continuous current
|
A
|
3
|
6
|
10
|
|
Sinusoidal continuous RMS current limit (Ic)
|
A
|
2.1
|
4.2
|
7.1
|
|
Peak current limit
|
A
|
2 x Ic
|
|
Feature
|
Units
|
R50/60
|
R80/80
|
R50/100
|
R70/100
|
R45/150
|
R15/200
|
|
Minimum supply voltage
|
VDC
|
8
|
10
|
10
|
10
|
12
|
20
|
|
Nominal supply voltage
|
VDC
|
48
|
65
|
85
|
85
|
115
|
170
|
|
Maximum supply voltage
|
VDC
|
55
|
75
|
95
|
95
|
135
|
195
|
|
Maximum continuous Electrical
power output
|
kW
|
2.3
|
5
|
4.0
|
5.6
|
5
|
2.5
|
|
Efficiency at rated power
(at nominal conditions)
|
%
|
> 99
|
|
Maximum output voltage
|
|
Up to 96% of DC bus voltage
|
|
Amplitude sinusoidal/DC
continuous current
|
A
|
50
|
80
|
50
|
70
|
45
|
15
|
|
Sinusoidal continuous RMS
current limit (Ic)
|
A
|
35.3
|
56.5
|
35.3
|
49.5
|
32
|
10.6
|
