NGT - Special Type
Type 43 Phenol Case
| Type | 43 |
| Operation Temp | 0℃ 〜 150℃ |
| Differential | Standards：10K 〜 30K |
| Temp Tolerance | Standards：±3～10℃ ※Depend on Operation Temp |
| Max Ambient Temp | 150℃ |
| Resistance between Terminals | Less than 30mΩ (Initial value) |
| Insulation Resistance | Not less than 1,000MΩ/DC500V |
| Dielectric strength | Not less than AC1,500V/1min.
Not less than AC1,800V/1sec |
| Endurance | More than 10,000cycles (Standards) |
