NGT - Thin Type
Type MH5 PPS Cover
| Type | MH5 |
| Operation Temp | 20℃ 〜 100℃ |
| Differential | Standards：10K 〜 30K |
| Temp Tolerance | Standards：±5～10℃ ※Depend on Operation Temp |
| Max Ambient Temp | 100℃ |
| Resistance between Terminals | Less than 30mΩ(Initial value) |
| Insulation Resistance | Not less than 1,000MΩ/DC500V |
| Dielectric strength | Not less than AC1,500V/1min.
Not less than AC1,800V/1sec |
| Endurance | More than 10,000cycles (Standards) |
