Type MH4 PBT Cover

NGT - Thin Type
Type MH4 PBT Cover

Type MH4
Operation Temp 0℃ 〜 70℃
Differential Standards:10K 〜 20K
Temp Tolerance Standards:±3~10℃ ※Depend on Operation Temp
Max Ambient Temp 70℃
Resistance between Terminals

Less than 50mΩ (L=120mm) (Initial value)

Insulation Resistance Not less than 1,000MΩ/DC500V
Dielectric strength Not less than AC1,500V/1min.
Not less than AC1,800V/1sec
Endurance More than 10,000cycles (Standards)
NGT - Type MH4 PBT CoverNGT - Type MH4 PBT Cover

03型フェノールケース

  • Compliance with RoHS Directives.
  • Splash proof equivalent to IP64.
  • Please feel free to ask us in case that operation temp, Diffential, Temp Tolerance is not standard.
