Type SS1 PBT Case

NGT - Splash - Water Proof Type
Type SS1 PBT Case

Type SS1
Operation Temp 0℃~100℃  (UL approval : Max. 105℃)
Differential Standards:8K~15K
Temp Tolerance Standards:±3~10℃ ※Depend on Operation Temp
Max Ambient Temp 105℃
Resistance between Terminals

Less than 50mΩ  (Initial value)

Insulation Resistance Not less than 1,000MΩ/DC500V
Dielectric strength Not less than AC1,500V/1min.
Not less than AC1,800V/1sec
Endurance More than 10,000cycles (Standards)
NGT - Type SS1 PBT CaseNGT - Type SS1 PBT Case

03型フェノールケース

  • Compliance with RoHS Directives.
  • Splash proof equivalent to IP64.
  • Please feel free to ask us in case that operation temp, Diffential, Temp Tolerance is not standard.
