Type 61 Phenol Case

NGT - Manuel Reset Type
Type 61 Phenol Case

Type 61
Operation Temp 40℃ 〜 120℃  Manual reset type.
Resetting by button Auto reset less than -0℃
Temp Tolerance Standards:±3~10℃ ※Depend on Operation Temp
Max Ambient Temp 120℃
Resistance between Terminals

61P :Less than 10mΩ(Initial value)

61N・61C :Less than 30mΩ (Initial value)

Insulation Resistance Not less than 1,000MΩ/DC500V
Dielectric strength Not less than AC1,500V/1min.
Not less than AC1,800V/1sec
Endurance More than 10,000cycles (Standards)
NGT - Type 61 Phenol CaseNGT - Type 61 Phenol Case


  • Compliance with RoHS Directives.
  • Splash proof equivalent to IP64.
  • Please feel free to ask us in case that operation temp, Diffential, Temp Tolerance is not standard.
