Type 25E Polyester Case

NGT - Manuel Reset Type
Type 25E Polyester Case

Type 25E
Operation Temp 40℃ 〜 150℃  No self automatic reset.
Available resetting Temp by button Below 30℃ from operating temp.
Temp Tolerance Standards:±3~10℃ ※Depend on Operation Temp
Max Ambient Temp 150℃
Resistance between Terminals 25EP :Less than 10mΩ(Initial value)
25EN :Less than 30mΩ (Initial value)
Insulation Resistance Not less than 1,000MΩ/DC500V
Dielectric strength Not less than AC1,500V/1min.
Not less than AC1,800V/1sec
Endurance More than 10,000cycles (Standards)
NGT - Type 25E Polyester CaseNGT - Type 25E Polyester Case

03型フェノールケース

  • Anti Tracking CTI 250V
  • Compliance with RoHS Directives.
  • This is not splash or water proof type.
  • Please feel free to ask us in case that operation temp, Diffential, Temp Tolerance is not standard.
