Type 15 Ceramic Case

NGT - Manuel Reset Type
Type 15 Ceramic Case

Type 15
Operation Temp 40℃ 〜 250℃  No self automatic reset.
Available resetting Temp by button Below 30℃ from operating temp.
Temp Tolerance Standards:±3~10℃ ※Depend on Operation Temp
Max Ambient Temp 250℃
Resistance between Terminals 15P :Less than 10mΩ(Initial value)
15N・15C :Less than 30mΩ (Initial value)
Insulation Resistance Not less than 1,000MΩ/DC500V
Dielectric strength Not less than AC1,500V/1min.
Not less than AC1,800V/1sec
Endurance More than 10,000cycles (Standards)
NGT - Type 15 Ceramic CaseNGT - Type 15 Ceramic Case


  • Compliance with RoHS Directives.
  • This is not splash or water proof type.
  • Please feel free to ask us in case that operation temp, Diffential, Temp Tolerance is not standard.
