Marathon SP Splicer / Distribution NEMA Power Blocks
60-2280 Amps, up to 600 Volts. Splicer power blocks provide the same number of wire inputs as outputs,
and distribution power blocks provide multiple load outputs per each incoming wire.
Electrical
• 60 - 2280 amps
• 600 volts AC/DC (UL)
• Flexible stranded wire compliant
• Multiple wire rating - refer to data sheets for details
• Listed products provide feeder circuit terminal spacing
Mechanical
• Base, black thermoplastic or phenolic (see chart)
• Insulator temp-ratings
• Thermoplastic: 125°C (257°F) - UL RTI
• Phenolic:150°C (302°F) - UL RTI
• Flammability, UL 94 V-0
• Mounting: panel mountable, 132 series is also DIN mountable
Standards
• See datasheets for product specific approvals listed
• UL listed - or - UL recognized
• Listed file no. QPQS.E309401 (UL 1953)
• Recognized file no. XCFR2.E62806 (UL 1059)
• CSA certified file no. LR19766 (CSA C22-2 No. 158)
• CE (Component IEC 60947-7-1)
• RoHS compliant (all)
Accessories
• Marking strips - available with custom printing
• Printing - consult factory for custom requests
